Cables : Network : SKU: A3L791-100

A3L791-100

Manufacturer: Belkin

Part Number: A3L791-100

UPC: 722868109199

Thinking of making a large purchase?

Belkin 100 ft. RJ45 CAT5e Patch Cable
$22.76

*FREE SHIPPING*

Free shipping to 48 states


IN STOCK!

Estimated Delivery with free shipping by:

Thursday April 04th*

* If ordered today with free shipping.

Features

  • Exceeds the performance requirement of Category 5e
  • Perfect in conjunction with 10 and 100 Base-T networks
  • 50-micron gold plated connectors to insure a clean and clear transmission
  • This product is guaranteed for life!
  • PowerSum tested

  • Specification

    Cable Length 100 ft.
    Characteristic Impedence 100±15O @ 1 ~ 350MHz
    Conductor Construction Bare Stranded Copper
    Conductor Resistance 89.2O/km/20°C max
    Conductor Size 24AWG x 4pairs
    Connector Type(s) 50 micron gold-plated connector
    Dielectric Strength AC 1.75kV/0.15sec
    Flame Retardant Test CM
    Insulation Material HDPE
    Jacket Diameter 5.5±0.15mm
    Jacket Material PVC
    Mutual Capacitance 56pF/m max
    Propagation Delay 538nS/100m max @ 350MHz
    Spark Test 2.5kV
    Standards Compliance ISO/IEC 11801; TIA/EIA-568-B.2
    Structural Return Loss 19.0dB min at 350MHz
