| Approvals | RoHS Compliant |
|---|---|
| Capacitance | 5600pf/100m |
| Color | Blue |
| Colors | Blue, Blue-White, Orange, Orange-White, Green, Green-White, Brown, Brown-White |
| Conductor DC Resistance | 9.38O100m (maximum) |
| Conductor Type | 24AWG (7/0.20), Stranded Bare Copper |
| Connector | 50 micron gold-plated RJ45 |
| Connector 1 | (1) RJ-45 Male |
| Connector 2 | (1) RJ-45 Male |
| Connector Material | Polycarbonate |
| Connector Type | 8P8C (RJ45) |
| Contact Material | Copper Alloy, Gold Plating - 50µm |
| Delay Skew | 45ns/100m (maximum) |
| Diameter | 0.98 ± 0.05mm |
| Gender | Male |
| Hood Material | Molded PVC |
| Impedance | 100O |
| Insulation | H-D PE |
| Jacket | PVC |
| Length | 10.00 Foot |
| Minimum Average Thickness | 0.60mm |
| Outer Diameter | 6.20 ± 0.30mm |
| Package Type | Polybag |
| Propagation Delay | 545ns/100m (maximum) |
| Standard | Category 6 TIA/EIA-568-B-2.1, draft 9 |
| Temperature Rating | 60°C |
| UPC | 757120271437 |
| Vendor | Cables To Go |
| Voltage Rating | 30V |
| Warranty | Lifetime |
| Weight | 0.250 LB |
| Wiring Scheme | T568B |
