Accessories : Power : Transformer : SKU: IS1000HGDV

IS1000HGDV

Manufacturer: Tripp Lite

Part Number: IS1000HGDV

UPC: 037332200020

Thinking of making a large purchase?

Tripp Lite Dual-Voltage 115/230V Transformer - Medical
$682.99

*FREE SHIPPING*

Free shipping to 48 states


BACKORDERED

Estimated Delivery with free shipping by:

Backordered - ETA Unknown

* If ordered today with free shipping.

Features

  • Transformer with full CAN/ES/IEC/EN 60601-1 listing
  • Offers line isolation, step-up and step-down capabilities, and continuous noise filtering
  • In protecting medical electronic equipment used in patient-care vicinities
  • Protects sensitive equipment from EMI/RFI line noise and surges
  • Cumulative leakage current less than 80 µA
  • Automatically shuts down all outlets in case of overload
  • Offers complete isolation from input AC mains power
  • Ideal for use in any industrial, network or medical environment
  • Full CAN/ES/IEC/EN 60601-1 Medical-Grade Listing with C14 Inlet and 8 C13 Outlets
  • Selectable 115/230V Input/Output Voltage Suitable for Most Applications
  • Protects Connected Equipment from Dangerous Spikes, Surges and Line Noise
  • 2-year limited warranty

  • Specification

    AC Suppression Joule Rating 240
    Color White
    Cooling Method Convection
    IEEE587 Cat. A Ringwave Let-Through Reduced to 0.5v Common Mode
    Input Current 10A @ 115V / 5A @ 230V
    Input Frequency 50/60HZ
    Leakage Current Max AC Leakage Current 80 (uA)
    Material of Construction Sheet Metal Cabinet
    Maximum Surge Amps 70A
    Noise Suppression Rating 35-65db
    Nominal Voltage / Frequency 115/230 VAC 50/60 HZ (Voltage Selected by Input Power Module Fuse Installation
    Output (Watts) 1000
    Output Isolation Transformer Toroid with AC output Floating with Respect to Earth Ground POAG Connector and Earth Ground Stud
    Output Receptacles (8) C13
    Over Current Protection 2X10A @ 115V and 2X5A at 230V ( Both Fuses included with Product as Accesories)
    Power Input Receptacle IEC-320-C14
    Product Warranty Period (Worldwide) 2-year limited warranty
    VA / Watt Capacity 1000

    In The Box

  • Transformer
  • 2 x Fuse Sets (115V and 230V Operation)
  • Input/Output Cable Selector Data Sheet
  • Owner's Manual
